OLED Display 0.91" 128x32 I2C IIC Serial 23mm White LCD Module 12832 SSD1306

OLED Display 0.91" 128x32 I2C IIC Serial 23mm White LCD Module 12832 SSD1306

Regular price $8.30 AUD
Regular price Sale price $8.30 AUD
Sale Sold out
Taxes included. Shipping calculated at checkout.

0.91 Inch 128x32 IIC I2C Serial OLED LCD White Display (1x Unit)

$6 Express Post and Free Standard Post available. (See postage options below)

A compact module that is packed with some of the latest display tech. The OLED display is self illuminating, requiring no backlights at all. For this reason, OLED's will allow a superior contrast from all angles.

With the I2C Interface, it limits the amount of pins needed to connect this module. Some microcontrollers like Arduinos have very few pin resources to use. The I2C interface allows data display with only two pins.

Specifications;

Display Technology: OLED

Display Interface: I2C interface Display

OLED/Text Colour: White

Driver IC (integrated circuit chip) : SSD1306

Device Size: 0.91 inch OLED

Resolution: 128 x 32

Supply Voltage: 3.3-5 Volts

Default I2C Address: 0x3C / 0x3D

Board Colour: May be Blue or Black


Connections;

GND: Power Ground (Solder/Pin)

VCC: Power + (DC 3.3 ~5v) (Solder/Pin)

SCL: Clock Line (Solder/Pin)

SDA: Data Line (Solder/Pin)
